Airtac 2WT Extra High Flow Solenoid Valve 2WT03008FI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT03008FI High Flow Solenoid Valve Specifications
- Model: 2WT03008FI
- Type: 5/2-way direct-acting (monostable)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.1–1.0 MPa
- Flow capacity: 3500 L/min (Cv=12.5)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 820g ±5%
- Dimensions: 150mm(L) × 80mm(W) × 65mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Response time: ≤50ms (exhaust to port A)
- Power consumption: ≤5.5W (AC), ≤4.8W (DC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high flow solenoid valve featuring rapid response and optimized flow paths for large pneumatic systems. The hexagonal body design enables tool-free manifold stacking. Includes manual override and status LED indicator. Requires 5μm filtered compressed air with oil mist lubrication (ISO 8573-1 class 3).
- High-speed packaging machinery actuators
- Plastic injection molding machine clamps
- Automotive tire assembly systems
- Industrial stamping press controls
- Large-scale pneumatic conveyor systems
Installation note:
Mount horizontally with arrow aligned to airflow direction.
Use copper-free anti-seize compound on threads.
Minimum 20mm clearance required above valve for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2WT03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
