Airtac 2WT Extra High Flow Solenoid Valve 2WT050-10-F
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-10-F High Flow Solenoid Valve Specifications
- Model: 2WT050-10-F
- Type: 5-port, 2-position (5/2-way) pilot-operated
- Port size: G3/8 (ISO 228 standard)
- Flow capacity: 8500 L/min (Cv=14.2, S=950)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Body material: Die-cast aluminum alloy (anodized finish)
- Protection rating: IP67 (water/dust resistant)
- Weight: 1.8 kg (with coil and connector)
- Dimensions: 150mm(L) × 85mm(W) × 125mm(H)
- Mounting type: ISO 15407-1 compliant flange mounting
Engineered for industrial heavy-duty applications, the 2WT050-10-F features a unique spool valve design with oversized flow paths, achieving 30% higher flow rates than standard models. Its full-bore structure minimizes pressure drop (ΔP≤0.02MPa @1.0MPa) while maintaining precise directional control. The valve incorporates a dual-coil thermal protection system with automatic current reduction after activation.
- High-speed packaging machinery (e.g., blister packaging lines)
- Plastic injection molding machine clamp units
- Automotive tire assembly systems
- Industrial vacuum pump control stations
- Food processing pneumatic conveying systems
Installation guidelines:
Requires filtered air (5-50μm) with recommended flow velocity ≤25m/s.
Maintain ≥30mm clearance around valve body for heat dissipation.
Use vibration-damping mounts in applications exceeding 15Hz mechanical frequency.
| Property | Property Value |
|---|---|
| sku | 2WT050-10-F |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
