Airtac 2WT Extra High Flow Solenoid Valve 2WT050-15-A
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-15-A High Flow Solenoid Valve Specifications
- Model: 2WT050-15-A
- Type: 5/2-way direct-acting with high flow design
- Port size: G1/2 (NPT3/4 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 6500 Nl/min (Cv=11.5) at 0.5 MPa
- Weight: 1.2 kg (with coil)
- Dimensions: 150mm(L) × 80mm(W) × 125mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: ≤4.5W (DC)/≤5.5VA (AC)
- Response time: ≤20ms (energize)/≤30ms (de-energize)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port thread depth: 15mm (minimum engagement)
High-performance large-flow solenoid valve engineered for industrial automation systems requiring rapid actuation and massive air throughput. Features dual-pressure compatibility and shock-resistant coil design with integrated surge protection. The optimized flow path reduces pressure drop by 30% compared to standard valves. Requires 25μm filtered compressed air with lubricator (ISO 8573-1:2010 Class 4.4.3).
- High-speed stamping press clutches/brakes
- Plastic injection molding machine ejectors
- Automotive tire assembly systems
- Paper converting equipment actuators
- Foundry air cylinder control systems
- Food packaging line pneumatic circuits
Installation guidelines:
Mount in vibration-damped position using M5 mounting screws (torque ≤1.2N·m).
Maintain 20mm clearance around exhaust ports for heat dissipation.
Perform monthly manual cycling during maintenance shutdowns.
| Property | Property Value |
|---|---|
| sku | 2WT050-15-A |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC220V |
