Airtac 2WT Extra High Flow Solenoid Valve 2WT050-15-B
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-15-B High Flow Solenoid Valve Specifications
- Model: 2WT050-15-B
- Type: 5/2-way monostable (direct-acting)
- Port size: G1/2 (NPT1/2 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Maximum flow rate: 3000 L/min (Cv=3.8)
- Voltage options: DC12V/24V ±10%, AC110V/220V ±10% 50/60Hz
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 150mm(L) × 80mm(W) × 120mm(H)
- Seal material: NBR/FKM (optional Viton)
- Temperature range: -10℃ to 60℃ (14℉ to 140℉)
- Response time: ≤50ms (exhaust to actuation)
- Power consumption: 4.5W (AC), 3.6W (DC)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 12mm (minimum engagement)
- Max cycling rate: 5Hz (300 cycles/minute)
High-performance large-flow solenoid valve with asymmetric flow paths for optimized directional control. Features anodized aluminum body with hardened stainless steel spool, designed for continuous operation in high-vibration environments. Requires 50μm filtered/dried air (dew point -20℃ below ambient).
- Injection molding machine cylinder control
- Pneumatic pressurization systems (automotive testing rigs)
- High-speed packaging line actuators
- Industrial vacuum pump switching
- Foundry equipment air blast control
Installation notes:
- Mount horizontally to prevent debris accumulation
- Install upstream filter regulator with auto-drain
- Use 20-30% below max pressure for optimal seal life
- Verify voltage matches local supply (±10% tolerance)
| Property | Property Value |
|---|---|
| sku | 2WT050-15-B |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
