Airtac 2WT Extra High Flow Solenoid Valve 2WT050-15-C
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-15-C High Flow Solenoid Valve Technical Details
- Model: 2WT050-15-C (Large Flow Series)
- Type: 5/2-way direct-acting solenoid valve
- Port size: G1/2 (BSPP thread standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 15 (at 7 bar)
- Response time: ≤20ms (energize), ≤30ms (de-energize)
- Temperature range: -5℃ to 50℃ (operating fluid), -20℃ to 60℃ (ambient)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Protection rating: IP67 (dust tight & protected against temporary immersion)
- Mounting type: Base plate mounting with ISO 5599/1 interface
- Weight: 1.8 kg (including coil)
- Dimensions: 150mm(L) × 80mm(W) × 120mm(H)
High-performance solenoid valve engineered for industrial systems requiring exceptional flow capacity (Cv15) and rapid cycling. Features optimized flow paths reducing pressure drop by 30% compared to standard valves. Rugged aluminum alloy body with chemical-resistant epoxy coating withstands harsh environments. Compatible with ISO VG32 hydraulic oil and standard pneumatic fluids.
- High-speed injection molding machine actuators
- Pneumatic punching press cylinder control
- Automated packaging line diverters
- Automotive tire assembly systems
- Bulk material handling gate valves
Installation Best Practices:
Install downstream air filter (5μm minimum). Maintain minimum 50mm clearance
around valve for heat dissipation. Use flexible tubing connections to reduce
vibration transfer. Perform monthly manual override testing for emergency systems.
Voltage tolerance must stay within ±10% of rated specification.
| Property | Property Value |
|---|---|
| sku | 2WT050-15-C |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC 110V |
