Airtac 2WX Fluid Solenoid Valve 2WX03006B
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03006B Fluid Solenoid Valve Technical Details
- Model: 2WX03006B
- Valve type: 2-position 3-way (2WX series)
- Port thread: G1/8 (BSPP) with optional NPT1/8
- Actuation: Direct-acting (no minimum pressure required)
- Operation mode: Normally closed/Open optional
- Pressure range: 0.02–1.0 MPa
- Flow coefficient (Cv): 0.45
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 1.8W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM (Viton®) standard, optional NBR or EPDM
- Ambient temperature: -5℃ to 80℃ (with FKM seals)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (coil protection)
- Electrical connection: DIN43650 Form A
- Weight: 220g ±5% (excluding cable)
- Dimensions: 58mm(L) × 35mm(W) × 38mm(H)
The 2WX03006B features a robust stainless steel plunger system with dust-resistant plunger tube, designed for aggressive industrial environments. Its zero-pressure start capability and 1 million cycle durability make it ideal for intermittent duty applications. The valve body uses anodized aluminum alloy with multi-stage filtration compatibility (recommended 25μm filter).
- Coolant control in CNC machining centers
- Pneumatic clutch engagement in conveyor systems
- Vacuum generator switching in packaging lines
- Hydraulic pilot control circuits
- Medical gas mixing stations (with EPDM seals)
Maintenance protocol:
Lubricate spool assembly every 5,000 operating hours using ISO VG32 turbine oil.
Avoid mounting in vibration zones exceeding 1.5G acceleration. For horizontal installation,
use the optional bracket (P/N: BR-2WX03).
| Property | Property Value |
|---|---|
| sku | 2WX03006B |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
