Airtac 2WX Fluid Solenoid Valve 2WX03006C
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03006C Fluid Solenoid Valve Technical Details
- Model: 2WX03006C
- Type: 2-position 3-way (3/2-way), Normally Closed
- Port configuration: P (pressure), A (output), R (exhaust)
- Port size: G1/8 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage tolerance: ±10% (Standard options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (open/close)
- Flow coefficient (Cv): 0.45
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Body material: Die-cast aluminum alloy (anodized)
- Weight: 220g ±5% (including coil)
- Dimensions: 55mm(L) × 40mm(W) × 75mm(H) (manual override protrusion excluded)
- Protection rating: IP67 (coil), IP40 (valve body)
- Expected service life: ≥10 million cycles (under clean air conditions)
High-flow compact solenoid valve featuring dual-pressure operation capability and manual override function. The pressure-balanced poppet design ensures stable switching even under fluctuating line pressures. Includes LED status indicator and surge protection diode. Requires ISO 8573-1:2010 Class 3.4.3 compressed air (max 5mg/m³ oil content).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control for material handling systems
- Dual-pressure regulation in injection molding machines
- Air blast control for CNC chip removal systems
- Packaging machine clamp circuits
Installation guidelines:
Mount horizontally with actuator facing downward. Install upstream
5μm filter regulator. Allow 15mm clearance around coil for heat dissipation.
Use copper-free anti-vibration mount in mobile applications.
Not compatible with:
Flammable gases, steam, or aggressive chemicals. Avoid rapid
cycling (>5Hz) without consulting factory thermal derating charts.
| Property | Property Value |
|---|---|
| sku | 2WX03006C |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC 110V |
