Airtac 2WX Fluid Solenoid Valve 2WX03006F
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03006F Fluid Solenoid Valve Technical Details
- Model: 2WX03006F
- Type: 2-position 5-way direct-acting (monostable)
- Port configuration: 5 ports (P, A, B, R, S)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal materials: NBR (standard), optional FKM/Viton
- Ambient temperature: -5℃ to 60℃ (with NBR seals)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (coil assembly)
- Weight: 280g ±5%
- Dimensions: 54mm(W) × 40mm(H) × 115mm(L)
- Mounting: ISO 5599-1 standard sub-base compatible
High-flow directional control valve with reinforced polyamide body and brass core components. Features manual override button for system debugging and emergency operation. Optimized for rapid cycling applications with >10 million cycle durability. Requires 5μm filtration with oil mist lubrication (ISO 8573-1 class 4).
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery air circuit control
- Plastic injection molding machine actuators
- Automated material handling systems
- Bottle capping/packaging equipment
Installation guidelines:
Install with 50mm clearance above coil for heat dissipation. Use anti-vibration mounts
in high-cycle applications (>5Hz). Lubricate sliding parts every 3 months in continuous
operation environments. Not suitable for vacuum applications.
