Airtac 2WX Fluid Solenoid Valve 2WX03008A
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03008A Fluid Solenoid Valve Technical Details
- Model: 2WX03008A
- Type: 5/2-way monostable (single solenoid pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤15ms (open), ≤10ms (close)
- Ambient temperature: -5℃ to 50℃ (operating fluid must be ≥3℃)
- Seal material: HNBR rubber (nitrile hydrogenated)
- Weight: 0.42kg ±5%
- Dimensions: 55mm(W) × 50mm(H) × 100mm(L)
- Port thread depth: 12mm (both inlet and outlet)
- Protection rating: IP67 (dustproof & temporary immersion)
- Coil insulation class: Class F (155℃)
High-flow directional control valve with reinforced polymer core for aggressive media handling. Features dual-chamber design for rapid pressure equalization and manual override capability. The encapsulated coil assembly prevents fluid ingress during high-humidity operations. Requires ISO 8573-1:2010 Class 3 compressed air quality (max 5mg/m³ oil content).
- Plastic injection molding machine cylinder control
- CNC pneumatic tool changers with rapid cycling
- Beverage filling line actuator sequencing
- Semiconductor wafer handling vacuum/pressure switches
- Textile machinery air-jet looms
Maintenance protocol:
Lubricate spool shaft quarterly with ISO VG32 turbine oil.
Avoid mounting near high-frequency vibration sources (>50Hz) to prevent coil resonance.
Critical note:
When using with non-lubricated air systems, install upstream
oil mist injector to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | 2WX03008A |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC220V |
