Airtac 2WX Fluid Solenoid Valve 2WX03008CI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03008CI Fluid Solenoid Valve Specifications
- Model: 2WX03008CI
- Type: 5/2-way direct-acting (double solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W max | AC: 3.5VA max
- Flow capacity: Cv=0.8 (Kv=0.7)
- Response time: ≤20ms (energize), ≤15ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Valve body material: Reinforced PBT with UL94 V-0 flame rating
- Temperature range: -5℃ to 80℃ (operating fluid)
- Ambient temperature: -20℃ to 60℃
- Protection rating: IP67 (dustproof & waterproof)
- Interface type: DIN43650 Form A compatible
- Weight: 320g ±5g
- Dimensions: 60mm(L) × 50mm(W) × 30mm(H)
- Port thread depth: 12mm (minimum engagement)
High-speed 5-port pneumatic valve featuring dual-coil latching design for bistable control. The optimized flow path reduces pressure drop by 18% compared to previous generation models. Includes manual override and position indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Robotic gripper actuation systems
- Automated assembly line clamping devices
- Textile machinery cylinder control
- Battery production vacuum/pressure switching
- Semiconductor wafer handling equipment
Installation guidelines:
Mount with vibration-damping pads in high-frequency environments.
Maintain 15mm minimum clearance below valve for electrical connections.
Lubricate seals with ISO VG32 turbine oil if used in dry air systems.
| Property | Property Value |
|---|---|
| sku | 2WX03008CI |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC 110V |
