Airtac 2WX Fluid Solenoid Valve 2WX03008FI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03008FI Fluid Solenoid Valve Technical Details
- Model: 2WX03008FI
- Type: 2-position 3-way, normally closed (direct-acting)
- Port connection: G1/8 (BSPP thread)
- Operating medium: Compressed air (non-lubricated or lubricated)
- Pressure range: 0.05–1.0 MPa
- Flow coefficient (Cv): 0.65
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 3.5W max | AC: 4.2VA max
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal materials: NBR (standard), optional FKM/Viton®
- Ambient temperature: -5℃ to 60℃ (with 5℃ margin during startup)
- Protection class: IP67 (dustproof and waterproof)
- Port alignment: 3/2-way configuration (pressure port, outlet port, exhaust port)
- Manual override: Built-in emergency activation button
- Weight: 280g ±5g (with connector)
- Dimensions: 52mm(L) × 34mm(W) × 68mm(H) (excluding fittings)
- Mounting orientation: Any (horizontal/vertical)
- Service life: ≥10 million cycles (at rated conditions)
High-flow solenoid valve with brass body and stainless steel core tube, optimized for rapid cycling in pneumatic systems. Features surge protection circuitry and low-hysteresis design. Requires 5-40μm filtration (ISO 8573-1 class 4) with maximum 1% relative humidity. Compatible with ISO 15407-1 standards for industrial valves.
- Bottle filling machine pressure regulation
- Industrial dishwasher pneumatic actuators
- HVAC damper control systems
- Textile machinery air jet control
- Automated test equipment clamping mechanisms
- Water treatment backwash valve operation
Installation protocol:
Use vibration-resistant mounting brackets in high-shock environments.
Maintain minimum 30cm distance from high-frequency inverters.
Apply thread sealant only on male ports (PTFE tape prohibited).
| Property | Property Value |
|---|---|
| sku | 2WX03008FI |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
