Airtac 2WX Fluid Solenoid Valve 2WX05010BI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010BI Fluid Solenoid Valve Specifications
- Model: 2WX05010BI
- Type: 2-position, 5-port direct-acting (bi-directional control)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 230g ±5g (with connector)
- Dimensions: 60mm(L) × 40mm(W) × 32mm(H) (body only)
- Seal material: High-grade HNBR rubber (fluorocarbon optional)
- Temperature range: -10℃ to 80℃ (non-freezing operation)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Flow coefficient (Cv): 1.2 at 0.5 MPa
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (4 full threads)
A high-flow bidirectional control valve with zero pressure start capability, featuring brass body construction with anodized aluminum core. Designed for aggressive duty cycles (≥10 million operations), its low-hysteresis design maintains precise flow control in both vacuum and pressure applications. Compatible with air, inert gases, and light hydraulic fluids (ISO VG32 or lighter).
- Pneumatic cylinder sequencing in packaging lines
- Vacuum pump control in semiconductor manufacturing
- Coolant flow switching for CNC machines
- Bi-directional gas flow in analytical instruments
- Irrigation system pressure balancing
Installation protocol:
Mount in vibration-free environment using M4 mounting screws (not included).
For horizontal piping, orient exhaust ports downward. Lubricate with ISO VG32
turbine oil if used with compressed air. Replace seals every 8,000 operating hours
under continuous duty. Requires 5μm filtration upstream.
| Property | Property Value |
|---|---|
| sku | 2WX05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
