Airtac 2WX Fluid Solenoid Valve 2WX05010E
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010E Fluid Solenoid Valve Technical Details
- Model: 2WX05010E
- Type: 2-position, 2-way direct-acting (universal port design)
- Port size: G1/8 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 850 L/min (at 0.5 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.52 kg (with coil)
- Dimensions: 66mm(L) × 45mm(W) × 55mm(H)
- Valve body material: Die-cast aluminum alloy (anodized finish)
- Seal material: FKM fluorocarbon (standard), optional EPDM/NBR
- Fluid temperature range: -5℃ to 80℃ (with FKM seals)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection class: IP67 (coil), IP65 (valve body)
- Port alignment: Horizontal/vertical (360° rotatable manifold)
High-flow solenoid valve with corrosion-resistant construction, featuring dual-position control for precise fluid management in demanding environments. The universal port configuration allows bidirectional flow with 5μm filtered media. Enhanced EMC protection (30V/m RF immunity) ensures stable operation near industrial motors.
- Coolant control in CNC machining centers
- Hydraulic system pilot stage operation
- Lubrication oil distribution systems
- Chemical dosing pumps in water treatment
- Beverage filling line pressure regulation
- Semiconductor wafer cleaning equipment
Installation guidelines:
Mount with manifold bracket (torque ≤25N·m). For viscous fluids,
maintain ambient temperature ≥5℃ during operation. Install
downstream moisture trap when handling compressed air.
Media compatibility:
Not suitable for strong acids/alkalis or phosphate ester fluids.
Maximum viscosity: 32cSt. Cycle rate ≤5Hz continuous operation.
| Property | Property Value |
|---|---|
| sku | 2WX05010E |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
