Airtac 2WX Fluid Solenoid Valve 2WX05015E
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05015E Fluid Solenoid Valve Technical Details
- Model: 2WX05015E
- Type: 2-position 3-way direct-acting solenoid valve (NC/NO selectable)
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0~1.0 MPa (0.1 MPa minimum differential pressure)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Flow capacity: 1200Nl/min (Cv=1.8)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Seal materials: NBR (standard), optional FKM for high-temp
- Ambient temperature: -5℃ to 80℃ (NBR), -5℃ to 150℃ (FKM)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 320g ±5% (without connector)
- Dimensions: 55mm(L) × 42mm(W) × 82mm(H) (including mounting brackets)
- Port spacing: 18mm between inlet/outlet
- Electrical connection: DIN43650 Form A (direct plug-in)
High-flow compact solenoid valve with manual override function, featuring brass body with anodized aluminum coil housing. Designed for aggressive duty cycles (up to 30 million operations) with double-sealed plunger system. Requires 5μm filtration (40μm max particle size) and oil mist lubrication (ISO VG32 recommended). Compatible with compressed air, inert gases, and vacuum systems.
- Pneumatic cylinder directional control in assembly lines
- Vacuum pump sequencing in semiconductor manufacturing
- Medical gas distribution systems (oxygen/nitrogen)
- Textile machinery air jet control
- Beverage filling station pressure regulation
- Railway braking system pilot valves
Installation guidelines:
Mount with 10mm vibration dampening gap around valve. Use anti-seize compound on threads.
For vertical mounting, position coil upward. Cycle 3-5 times manually before power-on.
| Property | Property Value |
|---|---|
| sku | 2WX05015E |
| Port Size | PT 1/2 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
