Airtac 5V Solenoid Valve 5V11006A050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110-06A050 Solenoid Valve Specifications
- Model: 5V110-06A050 (5V11006A050)
- Type: 5/2-way single solenoid control (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC24V ±10%, AC110V ±10% (50/60Hz), AC220V ±10% (50/60Hz)
- Weight: ~320g (without connector)
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with 30-minute max at 80℃)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.8W (DC24V), 5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve engineered for precision pneumatic systems requiring rapid cycling. Features dual-chamber sealing technology that reduces internal leakage by 30% compared to standard models. The aluminum alloy body with anodized surface treatment ensures corrosion resistance in humid environments. Compatible with ISO 15407-1 standards for industrial valve mounting interfaces.
- High-speed packaging machinery sequencing
- Automated assembly line actuators
- Plastic injection molding machine clamp control
- Textile machinery air circuit switching
- Semiconductor handling equipment
Installation note:
For optimal performance, maintain ambient temperature below 60℃ and install with vibration-damping mounts in high-shock environments. Use 5μm filtration with automatic drainage. Lubricated air requires ISO VG32 turbine oil mist (1-2 drops/m³). Allow 15mm clearance below valve for manual override access.
| Property | Property Value |
|---|---|
| sku | 5V11006A050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
