Airtac 5V Solenoid Valve 5V11006B050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V11006B050 Solenoid Valve Technical Specifications
- Full model code: 5V110-06B050 (with manual override)
- Valve type: 5/2-way double pilot operated
- Port thread: G1/8 (ISO228 standard)
- Effective area: 18mm² (minimum actuation pressure 0.15MPa)
- Voltage specification: DC24V ±10% (coil class F insulation)
- Power consumption: 1.6W (inrush current ≤1.3A)
- Max operating pressure: 1.0MPa (test pressure 1.5MPa)
- Flow characteristics: CV=0.25 (Kv=0.22) @ 6 bar
- Response time: ≤25ms (at rated voltage)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Port alignment: ISO 5599/1 standard (foot mounting)
- Seal material: Heat-resistant NBR (replaceable cartridge)
- Weight: 235g ±5% (including coil and connector)
- Dimensions: 56mm(L) × 38mm(W) × 72mm(H) (excluding fittings)
- Protection rating: IP67 (coil protection to NEMA 4X)
- Expected lifespan: 50 million cycles (under clean air conditions)
High-speed 5-port pneumatic valve featuring dual solenoid operation with position memory function. The hardened aluminum body with anodized treatment resists chemical corrosion in harsh environments. Integrated LED status indicator and DIN-type plug connector enable quick maintenance. Requires 5μm filtered lubricated air (ISO 8573-1:2010 class 4.4.3) with 20-50 cSt oil viscosity.
- High-cycle pneumatic punching machines
- Automated bottle capping systems
- PCB handling robotic arms
- Textile machinery tension control
- Plastic injection molding ejectors
- Automotive part testing jigs
Installation protocol:
Mount horizontally with actuator facing downward. Use shock-absorbing brackets
in high-vibration environments. Perform quarterly lubrication port maintenance
(recommended ISO VG32 turbine oil). Minimum 12mm wrench clearance required for
manifold installation.
| Property | Property Value |
|---|---|
| sku | 5V11006B050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
