Airtac 5V Solenoid Valve 5V11006E050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V11006E050 Solenoid Valve Technical Details
- Model: 5V11006E050
- Type: 5/2-way single solenoid (spring return)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage: DC24V ±10% (coil class F)
- Weight: 180g ±5g
- Dimensions: 50mm(L) × 35mm(W) × 70mm(H)
- Flow capacity: 750 l/min (ANR)
- Seal material: Heat-resistant FKM fluorocarbon
- Temperature range: -10℃ to 90℃ (no freezing)
- Power consumption: 2.2W (inrush 4.5W)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9mm (minimum engagement)
High-flow directional control valve with optimized spool geometry for reduced pressure drop. Features dual-chamber sealing technology and gold-plated terminals for humid environments. Compatible with ISO 15407-1 standards. Requires 5μm filtered compressed air with lubricator (ISO 8573-1 class 4).
- Plastic injection molding machine actuators
- Automated assembly line cylinder control
- Textile machinery pneumatic circuits
- Beverage filling station valve clusters
- Semiconductor wafer handling robots
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain ≥15mm clearance
below valve for manifold heat dissipation. Use copper-free grease
on threads. Test cycle rate ≤5Hz for extended service life.
| Property | Property Value |
|---|---|
| sku | 5V11006E050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC24V |
