Airtac 5V Solenoid Valve 5V11006F200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110-06F200 Solenoid Valve Technical Details
- Model: 5V110-06F200
- Type: 5/2-way single solenoid spring return
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Proof pressure: 1.5 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 420g ±5% (including coil)
- Dimensions: 58mm(L) × 38mm(W) × 78mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow coefficient (Cv): 1.6
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port orientation: Universal (360° rotatable)
High-flow directional control valve with compact modular design, featuring manual override and LED status indicator. The aluminum body with corrosion-resistant coating ensures durability in harsh environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with oil mist concentration 1-2 drops/m³.
- Pneumatic cylinder sequencing in assembly lines
- Material handling systems (clamping/rotating mechanisms)
- Textile machinery air circuit control
- Plastic injection molding machine actuators
- Automated packaging equipment (double-acting cylinders)
Installation guidelines:
Mount with vibration-resistant brackets in horizontal orientation.
Use 5-7Nm torque for port connections. Allow 15mm clearance for
heat dissipation. Lubricate seals with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 5V11006F200 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC12V |
