Airtac 5V Solenoid Valve 5V110M5A050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5A050 Solenoid Valve Specifications
- Model: 5V110M5A050
- Type: 5/2-way single solenoid (pilot-operated)
- Port size: M5 (ISO G1/8 equivalent)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage: DC24V ±10% (Other options: DC12V/AC110V on request)
- Power consumption: 1.6W (standard coil)
- Response time: ≤15ms (at 0.5 MPa)
- Flow rate: 350 NL/min (Cv=0.27)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (with dry air)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9.5mm (with PTFE tape compatibility)
- Weight: 210g ±5g (with connector)
- Dimensions: 55mm(L) × 35mm(W) × 78mm(H) (excluding fittings)
High-speed 5-port pneumatic valve with manual override capability, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The optimized flow path design reduces pressure drop by 18% compared to previous generations. Requires 5μm filtered compressed air with oil mist ≤1mg/m³. Includes LED status indicator and surge protection circuit.
- Multi-axis pneumatic cylinder control systems
- Industrial robot end-effector tooling
- Textile machinery air circuit switching
- Semiconductor wafer handling equipment
- Automated test fixture clamping mechanisms
Installation guidelines:
Mount in vibration-free environment using M5×16mm screws (1.2Nm torque).
Maintain minimum 15mm clearance below valve for exhaust airflow.
Lubricate seals with ISO VG32 turbine oil if used in high-cycle applications (>500k operations/year).
| Property | Property Value |
|---|---|
| sku | 5V110M5A050 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | AC220V |
