Airtac 5V Solenoid Valve 5V110M5B050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5B050 Solenoid Valve Specifications
- Model: 5V110M5B050
- Type: 5/2-way single solenoid controlled (spring return)
- Port size: G1/8 (ISO228-1 standard)
- Thread type: Metal-sealed M5 connector for electrical interface
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage specification: DC24V ±10% (100% ED rated)
- Current draw: 0.38A @24VDC (9.1W)
- Response time: ≤15ms (exhaust to port A)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Temperature range: -5℃ to 80℃ (no ice formation)
- Protection rating: IP67 (dust/water resistant)
- Weight: 420g ±5% (including connectors)
- Dimensions: 56mm(L) × 44mm(W) × 98mm(H)
- Port orientation: Side entry/exhaust with bottom manifold mount
High-flow solenoid valve with optimized spool design for rapid cycling applications. Features anti-vibration terminals and corrosion-resistant anodized aluminum body. Compatible with ISO 15407-1 standards, requires 5μm filtered lubricated air (ISO 8573-1 class 4). Includes manual override and position indicator.
- Pneumatic cylinder sequencing in automotive assembly lines
- High-speed packaging machinery with ≤1 sec cycle times
- Plastic injection molding machine clamp controls
- Food processing equipment (FDA-compliant seals available)
- Robotic gripper systems requiring <50ms valve response
Installation guidelines:
Mount on flat surface with DIN rail adapter (optional). Maintain ≥15mm
clearance below valve for exhaust dispersion. Use M5 crimp terminals
with 0.75–1.5mm² wire gauge. Lubricate quarterly in high-cycle (>500k actuations/month) environments.
| Property | Property Value |
|---|---|
| sku | 5V110M5B050 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC24V |
