Airtac 5V Solenoid Valve 5V110M5B200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5B200 Solenoid Valve Technical Details
- Model: 5V110M5B200
- Type: 5/2-way monostable (single solenoid)
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel threads with O-ring seal
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Maximum flow rate: 650 l/min (Cv=1.2 at 0.5 MPa)
- Voltage specification: DC24V ±10% (coil class F)
- Power consumption: 2.2W (pulse-rated for 100% ED)
- Response time: ≤15ms (at rated pressure)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Temperature range: -5℃ to 80℃ (with dew point prevention)
- Protection rating: IP67 (dustproof and waterproof)
- Weight: 320g ±5% (including coil and connector)
- Dimensions: 56mm(L) × 34mm(W) × 76mm(H)
- Port alignment: 15mm center-to-center spacing
- Manual override: Built-in emergency push button
High-speed 5-port directional control valve with metal body construction, optimized for rapid cycling applications. Features low hysteresis design with copper-free aluminum alloy components for corrosion resistance in humid environments. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max particle size 5μm, oil content ≤1mg/m³).
- Automated assembly line actuators
- Textile machinery clamping systems
- Semiconductor wafer handling robots
- Beverage canning line diverters
- Lithium battery production equipment
Installation guidelines:
Mount with M5x0.8 mounting screws (max torque 1.2N·m). Maintain 15mm
clearance below valve for tubing connections. Use vibration-damping
washers in high-frequency applications (>5Hz cycle rate).
| Property | Property Value |
|---|---|
| sku | 5V110M5B200 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC24V |
