Airtac 5V Solenoid Valve 5V110M5C050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5C050 Solenoid Valve Technical Details
- Model: 5V110M5C050
- Type: 5/2-way single solenoid (monostable)
- Port configuration: 5 ports, 2 positions
- Port size: G1/8 (ISO228 standard)
- Thread type: Metric (M5x0.8 optional adapter available)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage: DC24V ±10% (coil class F insulation)
- Power consumption: 2.2W (at 20℃ ambient)
- Response time: ≤15ms (pressurized to full stroke)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Valve body: Anodized aluminum alloy (hard coat 40μm)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Protection rating: IP67 (dust/immersion protected)
- Weight: 280g ±5% (including coil and accessories)
- Dimensions: 56mm(L) × 38mm(W) × 72mm(H) (excluding fittings)
- Endurance: ≥10 million cycles (at rated conditions)
High-flow directional control valve with enhanced heat dissipation design, featuring a low-hysteresis plunger system for precise position control. The brass core tube and stainless steel spring ensure stable performance in humid environments. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particle size).
- Automated assembly line cylinder control
- Textile machinery pneumatic actuators
- Plastic injection molding ejector systems
- Food processing equipment (dry applications)
- Semiconductor wafer handling robots
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (max 0.5Nm torque).
Maintain 15mm clearance above valve for heat dissipation. Lubricate with ISO VG32
turbine oil if used in high-cycle applications (>5Hz switching).
| Property | Property Value |
|---|---|
| sku | 5V110M5C050 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | AC 110V |
