Airtac 5V Solenoid Valve 5V110M5E200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5E200 Solenoid Valve Specifications
- Model: 5V110M5E200
- Type: 5/2-way direct-acting (monostable)
- Port size: PT1/8 (M5 x 0.8 threaded port)
- Operating pressure: 0.15–0.7 MPa
- Voltage: DC24V ±10% (coil class F)
- Power consumption: 1.2W (0.05A @24VDC)
- Flow coefficient (Cv): 0.7
- Response time: ≤15ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9.5mm (recommended engagement)
- Weight: 195g ±5g (including coil)
- Dimensions: 80mm(L) × 30mm(W) × 65mm(H)
High-speed 5-port pneumatic valve with copper-free aluminum alloy body, optimized for rapid cycling applications. Features low hysteresis design with PTFE piston guides for smooth operation. Requires 5-40μm filtered compressed air (ISO 8573-1 class 4). Compatible with vacuum systems when paired with AirTAC VCH series accessories.
- High-speed pick-and-place robotic end effectors
- Plastic injection molding machine ejectors
- Beverage canning line pneumatic controls
- Pharmaceutical blister packaging systems
- Automotive part testing jigs
Installation guidelines:
Mount with M5 screws (2.5Nm torque max). Maintain ≥15mm clearance
below valve for exhaust airflow. Use AirTAC VCH-03 silencers for
noise-sensitive environments. Lubricate seals with ISO VG32 turbine
oil annually.
| Property | Property Value |
|---|---|
| sku | 5V110M5E200 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | AC24V |
