Airtac 5V Solenoid Valve 5V110M5F050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5F050 Solenoid Valve Specifications
- Model: 5V110M5F050
- Type: 5/2-way monostable (direct acting)
- Port size: M5 (ISO 228 G1/8 equivalent)
- Operating pressure: 0.1–1.0 MPa
- Voltage: DC24V ±10% (coil insulation class F)
- Power consumption: 1.6W (standard), 0.8W (power-saving mode)
- Flow capacity: 650 l/min (ANR)
- Response time: ≤15ms (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (with 0.5-1.0 MPa)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 8mm (maximum engagement)
- Weight: 220g ±5g (including coil)
- Dimensions: 54mm(L) × 36mm(W) × 45mm(H)
High-speed 5-port pneumatic valve optimized for precise directional control in automated systems. Features dual-pressure operation capability and built-in surge protection circuitry. The aluminum alloy body with hard anodizing ensures durability in humid environments. Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality.
- Robotic gripper actuator control
- CNC machine tool clamping systems
- Bottle filling line diverters
- Textile machinery air cylinder control
- Lithium battery production equipment
Installation guidelines:
Mount with DIN rail adapter (optional 35mm rail clip). Maintain minimum
15mm clearance below valve for exhaust flow. Use copper-free lubricants
if required. For continuous operation, ensure ambient temperature remains
below 60℃.
| Property | Property Value |
|---|---|
| sku | 5V110M5F050 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC12V |
