Airtac 5V Solenoid Valve 5V110M5F200
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V110M5F200 Solenoid Valve Technical Specifications
- Model: 5V110M5F200
- Type: 5/2-way monostable (single solenoid)
- Port configuration: M5 threaded (ISO 228/1 standard)
- Port size: 1/8" BSPP equivalent
- Operating pressure range: 0.1–0.7 MPa (14.5–101.5 PSI)
- Proof pressure: 1.05 MPa
- Voltage options: DC24V (±10%), DC12V (customizable)
- Power consumption: 1.8W (standard), 0.45W (power-saving mode)
- Response time: ≤15ms (exhaust to actuation)
- Flow coefficient (Cv): 0.12
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -10℃ to 60℃ (with condensation prevention)
- Weight: 210g ±5g (with connector)
- Dimensions: 58mm(L) × 35mm(W) × 48mm(H) (excluding fittings)
- Port thread depth: 9mm (minimum engagement required)
- Protection rating: IP67 (dust/immersion protection)
- Cycle life: ≥10 million operations (under rated conditions)
High-speed directional control valve featuring low hysteresis and energy-efficient operation. The 5V110M5F200's reinforced epoxy coil housing provides EMI/RFI shielding and chemical resistance. Optimized for vacuum applications (down to -95kPa) with dual-chamber pressure balancing. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Semiconductor wafer handling robotics
- Precision pneumatic gripper sequencing
- CNC machine tool clamping systems
- Cleanroom-compatible automation (ISO Class 5)
- Food-grade pneumatic circuits (FDA-compliant variants available)
Installation protocol:
Mount with vibration-damping gaskets in high-shock environments.
For vertical installations, position coil upward to prevent debris accumulation.
Perform weekly manual cycling during standby periods exceeding 30 days.
| Property | Property Value |
|---|---|
| sku | 5V110M5F200 |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC12V |
