Airtac 5V Solenoid Valve 5V12006A050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V120-06A050 Solenoid Valve Technical Details
- Model: 5V120-06A050 (Full designation 5V12006A050)
- Type: 5/2-way single solenoid spring return
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage specifications: DC24V (±10%) with DIN43650 connector
- Power consumption: 2.2W (0.09A @24VDC)
- Flow capacity: CV 1.2 / KV 1.4 (at 7 bar)
- Response time: ≤20ms (energize)/≤15ms (de-energize)
- Seal materials: HNBR rubber (high-temp variant available)
- Temperature tolerance: -10℃ to 80℃ (standard) / -20℃ to 120℃ (special seals)
- Body material: Die-cast aluminum with epoxy coating
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5g (including coil)
- Dimensions: 58mm(L) × 45mm(W) × 72mm(H)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with optimized magnetic circuit design for stable operation under pressure fluctuations. Features dual-chamber design to prevent cross leakage and integrated surge protection diode. Requires 5μm filtered dry air (lubricated/non-lubricated compatible).
- Pneumatic clamping systems in CNC machinery
- Automated production line actuator control
- Plastic injection molding ejector mechanisms
- Textile machinery tension control systems
- Automotive tire assembly equipment
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤0.8Nm).
Maintain 15mm clearance below valve for manifold access. Use PTFE tape on ports
with clockwise tightening (do not overtighten - max 25Nm). Perform monthly
manual cycling if used intermittently.
| Property | Property Value |
|---|---|
| sku | 5V12006A050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
