Airtac 5V Solenoid Valve 5V12006B050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V12006B050 Solenoid Valve Technical Specifications
- Model: 5V12006B050
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Flow capacity: 1,200 L/min (Cv=1.3)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 54mm(L) × 42mm(W) × 73mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 60℃ (fluid temperature), -20℃ to 70℃ (ambient)
- Power consumption: 2.8W (DC24V), 3.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9.5mm (PT1/4)
High-flow 5/2-way valve featuring zero pressure start capability and optimized pilot structure for stable operation in low-vibration environments. The aluminum alloy body with hard anodized finish ensures corrosion resistance in humid conditions. Includes manual override and LED status indicator (on select voltage models). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Plastic injection molding machine clamp units
- Automated assembly line cylinder control
- Textile machinery tension control systems
- Food processing pneumatic actuators
- Semiconductor wafer handling robots
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain minimum 15mm
clearance below valve for exhaust flow. Use shock-absorbing
brackets in high-cycle applications (>5Hz). Lubricate with ISO VG32
turbine oil if operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 5V12006B050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
