Airtac 5V Solenoid Valve 5V12006E050
2、Terminal-type electrical connection with concentrated internal pilot exhaust, suitable for pollution-free workplaces requiring special environmental conditions;
3、Spool-type structure ensures excellent sealing performance and rapid response; multiple standard voltage ratings available;
4、3-position solenoid valves offer three center function options; double solenoid 2-position valves feature memory function;
5、Precision-machined inner bore minimizes friction resistance, enables low actuation pressure, and extends service life;
6、Compatible with modular valve banks for space-saving installation; integrated manual override facilitates commissioning and maintenance.
Category: Solenoid Valves , Brand: AIRTAC , Series: 5V
AirTAC 5V12006E050 5-Way Solenoid Valve Specifications
- Model: 5V12006E050
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V ±10% (standard), custom AC options available
- Flow coefficient (Cv): 1.3
- Response time: ≤15ms (at rated voltage)
- Weight: 220g ±5% (without connector)
- Dimensions: 60mm(L) × 45mm(W) × 80mm(H)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Temperature range: -5℃ to 60℃ (with intermittent 80℃ tolerance)
- Power consumption: 3.5W (at DC24V)
- Protection rating: IP67 (dust-tight and protected against immersion)
- Port thread depth: 10mm (minimum engagement)
- Manual override: Optional paddle-type override
High-flow 5-port solenoid valve featuring dual coil operation for precise directional control in pneumatic circuits. The pilot-operated design ensures reliable switching under variable pressure conditions. Includes surge protection circuitry and brass core construction for enhanced durability in humid environments. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line cylinder sequencing
- Plastic injection molding machine actuators
- Pharmaceutical blister packaging systems
- Food processing pneumatic grippers (FDA-compliant versions available)
- Textile machinery tension control
Installation guidelines:
Mount horizontally (±15° tolerance) with exhaust ports oriented downward.
Use copper-free anti-seize compound on threads. Maintain minimum 20mm
clearance below valve for condensate drainage. Lubricate with ISO VG32
turbine oil if air line lubrication is absent.
| Property | Property Value |
|---|---|
| sku | 5V12006E050 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC24V |
