Airtac 6V Solenoid Valve 6V230E06C050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V230E06C050 Solenoid Valve Technical Profile
- Full model designation: 6V230E06C050
- Valve type: 5/2-way double pilot operated (bi-stable)
- Port configuration: G1/4" BSPP female threads
- Effective section area: 23mm² (Cv=1.3)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil insulation class: F grade (155℃)
- Response time: ≤25ms (at 0.5MPa)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Fluid temperature: 0-60℃ (lubricated air required below 0℃)
- Seal material: HNBR (hydrogenated nitrile) for enhanced oil resistance
- Protection class: IP67 (dust tight & protected against temporary immersion)
- Weight: 450g ±5% (including coil and accessories)
- Dimensions: 76mm(L) × 44mm(W) × 63mm(H) (excluding manifold protrusions)
- Manual override: Built-in mechanical override button
- Porting pattern: ISO 5599-1 standard (compliant with multiple brand manifolds)
High-flow 5/2 pneumatic valve engineered for industrial automation systems requiring reliable bidirectional cylinder control. Features low-hysteresis pilot mechanism with gold-plated connectors for stable signal transmission. The aluminum alloy body with hard anodized finish resists chemical corrosion in harsh environments. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Robotic arm end-effector position switching
- Plastic injection molding machine clamp control
- CNC tool changer pneumatic sequencing
- Automotive assembly line fixture actuation
- Food processing equipment (requires NSF-H1 lubricant)
Installation protocol:
Mount on ISO-standard manifold using M5x16mm hex screws (12N·m torque limit).
Maintain 50mm clearance below valve for service access. Perform monthly
blow-down of pilot ports in high-humidity environments.
- AirTAC SCP-04 silencer (noise reduction to 65dB)
- FRL unit with 0.3μm filtration (AS-2002F series)
- Coil surge protector: Zener barrier diode module
| Property | Property Value |
|---|---|
| sku | 6V230E06C050 |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
