Airtac ACKDL Rotary Type Cylinder ACKDL50X90
2. Triple-guide groove structure delivers high-precision alignment and directional stability;
3. Available in single-acting and double-acting (90°) operation configurations;
4. Flexible rotation options: left-hand/right-hand rotation with 90° and 180° rotation angles;
5. Heat-treated piston rod manufactured from special alloy steel guarantees enhanced durability and prolonged service life.
Category: Angular Rotation Cylinders | Brand: AirTAC | Series: ACKDL
AirTAC ACKDL50X90 Rotary Clamp Cylinder Specifications
- Model: ACKDL50X90
- Type: Double-acting rotary clamp cylinder
- Bore size: Ø50 mm
- Stroke: 90 mm
- Rotation angle: 90°±1° (standard)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Rubber buffer + adjustable cushion
- Mounting orientation: Any direction
- Piston speed: 50-750 mm/s
- Port size: G1/8 (NPT1/8 optional)
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Weight: 2.8 kg ±3%
- Dimensions: 163mm(L) × 50mm(W) × 94mm(H)
- Rod thread: M12×1.25
- Protection rating: IP54 (standard)
Compact 90° rotary actuator with integrated linear stroke, featuring twin-piston torque amplification design for high rotational force (14.7 N·m at 0.6 MPa). The hardened guide rod and dual angular contact bearings ensure precise repeat positioning (±0.5° accuracy). Includes anti-rotation safety lock and wear-indicator windows.
- Workpiece flipping in robotic welding stations
- Clamping/unclamping in CNC fixture systems
- Part orientation in assembly conveyor transfers
- Valve actuation in food processing equipment
- Pallet rotation in automated warehouses
Installation note:
Lubricate guide rod with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-1 MPa air pressure during rotation to prevent seal abrasion.
Allow 20mm clearance for swing radius during mechanical design.
| Property | Property Value |
|---|---|
| sku | ACKDL50X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <50mm> |
| Direction Code | Push Down Left-hand Rotation |
| Rotation Angle Code | <90°> |
