Airtac AirTAC 2KW Fluid Control Valve 2KW03006A
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW03006A Fluid Control Valve Technical Specifications
- Model: 2KW03006A
- Type: 2-position 3-way normally closed (Direct-acting)
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: Fluorocarbon rubber (FKM) standard (NBR optional)
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 420g ±5% (including coil)
- Dimensions: 58mm(L) × 42mm(W) × 85mm(H) (excluding ports)
- Port orientation: Horizontal/vertical multi-directional mounting
High-flow proportional control valve with integrated pressure compensation, featuring brass body construction with electroless nickel plating for corrosion resistance. The direct-acting design eliminates minimum pressure requirements, enabling stable operation in vacuum applications. Includes manual override and surge protection circuitry.
- Pneumatic cylinder speed regulation systems
- Industrial vacuum pick-and-place equipment
- Beverage filling line pressure modulation
- Textile machinery tension control
- Semiconductor wafer handling robots
- Medical gas blending stations
Installation guidelines:
Install downstream of 5μm filter regulator. Allow 20mm clearance above coil for heat dissipation.
Use PTFE tape on male threads only. Cycle testing recommended before permanent mounting -
perform 5-10 actuations at 50% rated voltage for seating.
| Property | Property Value |
|---|---|
| sku | 2KW03006A |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
