Airtac AirTAC 2KW Fluid Control Valve 2KW03006B
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW03006B Fluid Control Valve Specifications
- Model: 2KW03006B
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 450 L/min (ANR)
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Response time: ≤30ms (exhaust to actuation)
- Weight: 320g ±5%
- Dimensions: 76mm(L) × 42mm(W) × 68mm(H)
- Seal material: FKM fluorocarbon (Viton® equivalent)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC24V), 3.2VA (AC220V)
- Protection rating: IP67 (dust/water resistant)
- Flow coefficient (Cv): 1.2
- Hysteresis: ≤10% of rated pressure
High-flow proportional control valve with brass body and corrosion-resistant plating. Features manual override button for system debugging and emergency operation. Designed for precise fluid regulation in both vacuum and pressure systems. Requires 25μm filtration with oil mist lubrication (ISO VG32 recommended).
- Industrial cooling system flow control
- Chemical dosing systems in water treatment plants
- Hydraulic pilot stage control
- Beverage dispensing machine fluid management
- Semiconductor manufacturing gas distribution
- Automated paint circulation systems
Installation notes:1. Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m)
2. Maintain minimum 15mm clearance below valve for drain port access
3. Use PTFE thread sealant on port connections (do not overtighten)
4. Recommended maintenance: Inspect seals every 5 million cycles
| Property | Property Value |
|---|---|
| sku | 2KW03006B |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
