Airtac AirTAC 2KW Fluid Control Valve 2KW03006C
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW Series Fluid Control Valve 2KW03006C Technical Specifications
- Model: 2KW03006C
- Valve type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 300 L/min (Cv=1.8)
- Response time: ≤15ms (at rated voltage)
- Body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Seal material: FKM fluorocarbon rubber (-30℃ to 120℃)
- Ambient temperature: -30℃ to 80℃ (non-freezing)
- Protection class: IP67 (dust/water resistant)
- Weight: 890g ±2% (without connectors)
- Dimensions: 80mm(L) × 42mm(W) × 75mm(H)
- Port thread depth: 10.5mm (tapered pipe thread conforming to JIS B0203)
- Coil insulation class: Class F (155℃)
- Certifications: RoHS, CE, ISO/CEI 60529 compliant
High-flow proportional control valve engineered for industrial automation systems requiring precise directional control. Features dual solenoid activation with manual override capability (push-button type). Optimized internal flow paths reduce pressure drop by 18% compared to previous generation models. Compatible with ISO 5599/1 mounting interfaces.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (NSF-H1 grease compatible)
- Wastewater treatment plant valve clusters
- Semiconductor fab equipment (cleanroom compatible)
Operational guidelines:
Install upstream 5μm filter with auto-drain. Avoid rapid cycling (>5Hz) without
heat dissipation measures. For horizontal mounting, use support bracket (P/N: BR-2KW-01).
Lubricate with ISO VG32 turbine oil if used in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2KW03006C |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
