Airtac AirTAC 2KW Fluid Control Valve 2KW03006F
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW03006F Fluid Control Valve Technical Details
- Model: 2KW03006F
- Type: 3-position, 5-way pilot-operated solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with connectors)
- Dimensions: 58mm(L) × 44mm(W) × 78mm(H) (excluding mounting brackets)
- Seal materials: HNBR (hydrogenated nitrile) with PTFE backup rings
- Temperature tolerance: -10℃ to 80℃ (with intermittent peak at 100℃ for ≤30 mins)
- Flow capacity: 850 L/min (Cv value 1.2 at 0.5 MPa)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
High-flow electro-pneumatic valve featuring dual-pressure capability and shock-resistant coil design. The hardened aluminum alloy body with anodized finish ensures corrosion resistance in humid environments. Incorporates a manual override button for emergency operation and status indication window. Requires 5μm filtration with automatic drain function for optimal performance.
- Automated assembly line clamping/unclamping systems
- Plastic injection molding machine ejectors
- Beverage filling station pneumatic circuits
- Semiconductor wafer handling robotics
- Wastewater treatment plant actuator control
Installation protocol:
Mount horizontally with ports downward to prevent debris accumulation.
Use anti-vibration washers in high-cycle applications (>1.5M operations/year).
Lubricate seals with ISO VG32 pneumatic oil if used in dry gas systems.
| Property | Property Value |
|---|---|
| sku | 2KW03006F |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
