Airtac AirTAC 2KW Fluid Control Valve 2KW05010AI
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010AI Fluid Control Valve Technical Specifications
- Model: 2KW05010AI
- Type: 5-port 3-position closed center (closed transition)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 1,200 NL/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil protection class: Class F (155℃)
- Weight: 780g ±5% (including coil)
- Dimensions: 120mm(L) × 85mm(W) × 55mm(H)
- Seal materials: HNBR (hydrogenated nitrile) main seals, FKM optional
- Temperature range: -10℃ to 80℃ (with silicone seals up to 120℃)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Manual override: Built-in mechanical override button
- Certifications: RoHS compliant, CE marked
High-flow proportional control valve with closed-center functionality, featuring dual-pressure compensation and anti-vibration coil design. The aluminum alloy body with hard anodized treatment ensures durability in humid environments. Requires 5μm filtration (40μm for emergency use) and lubricated air (ISO VG32 grade or equivalent).
- Plastic injection molding machine clamp control
- Automated assembly line pressure sequencing
- Textile machinery tension regulation systems
- Semiconductor wafer handling vacuum/pressure switching
- Electric vehicle battery cooling system flow control
Installation guidelines:
Mount with vibration-damping brackets in high-frequency applications.
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Use thread sealant (LOCTITE 545 or equivalent) on port connections.
- Lubrication interval: 3 months (continuous operation)
- Diaphragm inspection: 10,000 cycles or 12 months
- Coil resistance check: 6 months (nominal ±15%)
| Property | Property Value |
|---|---|
| sku | 2KW05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
