Airtac AirTAC 2KW Fluid Control Valve 2KW05010B
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010B Fluid Control Valve Technical Specifications
- Model: 2KW05010B
- Type: 5-port 3-position closed center (pneumatic)
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 1,200 NL/min (Cv=1.8)
- Voltage options: DC12V (2W), DC24V (2.5W), AC110V (3.5VA), AC220V (4VA)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 680g ±2% (with solenoid)
- Dimensions: 98mm(L) × 45mm(W) × 92mm(H)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Compatible fluids: Compressed air (ISO 8573-1:2010 Class 3.4.3)
- Lubrication: Non-required (oil-free operation)
High-flow proportional control valve with center-block function, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual solenoid design enables precise mid-position control in pneumatic circuits. Integrated LED status indicator and manual override button simplify troubleshooting. Requires 5μm filtration and dew point -20℃ compressed air.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position hold requirements
- Material handling equipment with safety interlocks
- Textile machinery tension control systems
Installation guidelines:
Mount horizontally with arrow aligned to flow direction. Use flexible tubing
connections to prevent vibration transfer. Allow 15mm clearance below valve
for solenoid heat dissipation. Perform weekly manual cycling in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | 2KW05010B |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
