Airtac AirTAC 2KW Fluid Control Valve 2KW05010BI
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010BI Fluid Control Valve Specifications
- Model: 2KW05010BI
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±5% (including coil)
- Dimensions: 55mm(L) × 42mm(W) × 78mm(H)
- Flow rate: 1,200 NL/min (ANR) at 0.5 MPa
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Power consumption: 2.8W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with metal seal options, featuring low hysteresis and zero-pressure start capability. The dual-coil heat dissipation design ensures stable operation in continuous duty cycles. Compatible with ISO 15407-1 standards, it supports both vacuum and pressure applications. Requires 25μm filtered compressed air or inert gases.
- Automated production line sequencing systems
- Plastic injection molding machine actuators
- Semiconductor wafer handling equipment
- Beverage filling station pneumatic circuits
- Textile machinery tension control systems
Installation note:
Mount with vibration-damping gaskets in high-frequency operation environments.
For horizontal installation, ensure exhaust ports face downward. Lubricate sliding
surfaces with ISO VG32 pneumatic oil monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2KW05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
