Airtac AirTAC 2KW Fluid Control Valve 2KW05010C
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010C Fluid Control Valve Specifications
- Model: 2KW05010C
- Type: 2-position 3-way, normally closed (direct-acting)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (Cv=1.3)
- Response time: ≤15ms (at rated voltage)
- Seal material: FKM (Fluorocarbon Rubber) / Optional EPDM
- Temperature range: -5℃ to 80℃ (FKM), -10℃ to 60℃ (EPDM)
- Protection rating: IP67 (dustproof & waterproof)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H)
High-performance fluid control valve with optimized flow path design, featuring low power consumption (2W nominal) and zero-pressure start capability. The brass body with hard chrome plating ensures corrosion resistance in humid environments. Includes manual override and status indicator LED (selectable in some variants).
- Industrial automation pneumatic circuits
- Coolant control in CNC machining centers
- Vacuum generator systems
- Food processing equipment (EPDM seal version)
- Hydraulic pilot stage control
- Semiconductor manufacturing gas control
Installation guidelines:
Maintain minimum 2x port diameter straight piping upstream.
Use vibration dampeners when mounted on equipment with >5G vibration.
Lubricate with ISO VG32 turbine oil if using dry air supply.
| Property | Property Value |
|---|---|
| sku | 2KW05010C |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
