Airtac AirTAC 2KW Fluid Control Valve 2KW05010CI
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010CI Fluid Control Valve Technical Specifications
- Model: 2KW05010CI
- Type: 3-position, 5-port directional control valve (closed center)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 2.2W (at DC24V)
- Flow capacity: 850 L/min (ANR)
- Weight: 480g ±5% (including coil)
- Dimensions: 62mm(W) × 45mm(H) × 135mm(L)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center configuration, featuring precision-machined spool mechanism for stable mid-position cutoff. The aluminum body with nickel-plated brass fittings provides corrosion resistance in humid environments. Requires 5μm filtration (ISO 8573-1:2010 Class 3.6.2) and lubricated air (ISO VG32 equivalent).
- Bottle filling machine pressure sequencing
- Plastic injection molding clamp control
- Automated conveyor braking systems
- Industrial dishwasher water flow management
- CNC machine tool chuck actuators
Maintenance protocol:
Perform manual cycling every 6 months if used in low-cycle applications.
Use 0.5-0.8MPa test pressure for leakage checks (max 20 bubbles/min in soap test).
| Property | Property Value |
|---|---|
| sku | 2KW05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
