Airtac AirTAC 2KW Fluid Control Valve 2KW05010E
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010E Fluid Control Valve Technical Specifications
- Model: 2KW05010E
- Type: 5-port, 3-position closed center (pneumatic directional control)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 70mm(L) × 42mm(W) × 85mm(H)
- Seal material: FKM fluorocarbon (standard), EPDM optional
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Power consumption: ≤2.5W (DC24V)
- Flow capacity: 850 NL/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Fluid compatibility: Clean compressed air (ISO 8573-1:2010 Class 3.4.2)
- Protection rating: IP67 (coil), IP40 (valve body)
- Mounting orientation: Any (horizontal recommended for optimal drainage)
- Certifications: RoHS, REACH, CE
High-flow proportional control valve with closed-center spool design, engineered for precision pressure regulation in industrial automation systems. Features dual-pressure operation capability and shock-resistant brass body with nickel plating. Requires 5μm filtration and automatic drain maintenance.
- Robotic gripper pressure modulation systems
- CNC machine tool clamping circuits
- Beverage filling line pressure sequencing
- Lithium battery production gas control
- Pharmaceutical packaging air logic systems
Installation note:
Maintain minimum 20mm clearance below valve for condensate drainage.
Use M3 mounting screws with 0.4-0.6Nm torque. Lubricate seals with
ISO VG32 turbine oil if operating below -5℃.
Critical parameters:
Maximum allowable leakage ≤0.15 NL/min at 0.5MPa.
Cycle life ≥5 million operations (per EN 60534-6).
| Property | Property Value |
|---|---|
| sku | 2KW05010E |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
