Airtac AirTAC 2KW Fluid Control Valve 2KW05010F
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010F Fluid Control Valve Specifications
- Model: 2KW05010F
- Type: 3-position, 5-way closed center (pneumatic pilot operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: ~350g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: Dual-sealed with NBR and FKM options
- Temperature range: -20℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Flow capacity: 850 L/min (ANR)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
High-flow proportional control valve with position feedback capability, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual-pressure balanced spool design ensures stable operation under fluctuating loads. Requires 5μm filtered dry air and 20-30cSt viscosity lubricant (optional).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Food processing pneumatic circuits (FKM seal version)
- Lithium battery production equipment
- High-cycle packaging machinery
Installation note:
Maintain vertical mounting position (±15° tolerance). Install vibration dampeners when used with reciprocating compressors.
Allow 20-minute run-in period at 0.3MPa before full-load operation.
- Lubrication interval: 3 million cycles or 6 months
- Seal replacement: 10 million cycles or 2 years
- Coil insulation check: Annual dielectric strength test at 1.5kV
| Property | Property Value |
|---|---|
| sku | 2KW05010F |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
