Airtac APC Threaded Quick Connect Coupling APC12-M12
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC12-M12 Threaded Quick-Connect Coupling Technical Details
- Model Series: APC (Advanced Pneumatic Connection)
- Thread Specification: M12×1.25 male thread (ISO 1179-1 standard)
- Tube Compatibility: 12mm OD polyurethane/nylon tubing
- Body Material: Nickel-plated brass (EN 12165 CW617N)
- Seal Material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Operating Pressure: 0.05-1.2 MPa (7-174 PSI)
- Burst Pressure: ≥4.0 MPa (580 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Flow Rate: 200 NL/min @ 0.5 MPa
- Leakage Rate: ≤3 bubbles/min (ISO 6952 test standard)
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
- Weight: 48g ±2g (with protective cap)
- Dimensions: 38mm(L) × 24mm(W) × 24mm(H)
- IP Rating: IP40 (protected against 1mm solid objects)
High-flow pneumatic coupling with 360° rotatable sleeve design enables tool-free tube insertion. Features dual-stage sealing with dust-resistant check valve mechanism. The anti-vibration structure maintains stable connections in mobile equipment applications. Compatible with ISO 14743 standards for pneumatic quick-action couplings.
- Robotic arm end-effector pneumatic tooling
- CNC machine tool coolant line connections
- Food processing equipment (oil/moisture-resistant version available)
- Mobile hydraulic test bench manifolds
- Semiconductor wafer handling vacuum systems
Installation protocol:
Apply 2-3 drops of pneumatic oil (ISO VG32) to O-ring before initial use.
Tighten to 15-20 N·m torque using 22mm open-end wrench. Maximum allowable
lateral tube load: 30N. Replace collet springs after 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | APC12-M12 |
| Insert Tube | 12mm |
| Threaded Port | M12 |
