Airtac APC Threaded Quick Connect Coupling APC16-M20
$7.97
Regular price
$15.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC16-M20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Cut tubing square with dedicated cutter, deburr edges, and insert fully until audible click.
For maintenance, depress collar fully while pulling tubing. Max torque 45N·m during threading.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC16-M20 Threaded Quick Connector Specifications
- Model: APC16-M20
- Thread standard: M20×1.5 (ISO 228-1)
- Tube compatibility: Ø16mm OD pneumatic tubing
- Material: Nickel-plated brass body + PPSU/POM sleeve
- Seal type: Double-lip NBR O-ring
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Leakage rate: ≤0.1 NL/min @ 0.6 MPa
- IP rating: IP40 (protected against tool access)
- Weight: 128g ±2g
- Dimensions: 72mm(L) × 34mm(W) × 34mm(H)
- Thread engagement: 15mm minimum
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
High-flow push-to-connect fitting with 360° rotatable sleeve for flexible hose orientation. Features anti-vibration teeth and color-coded collar (standard blue). Includes built-in tube grip for secure retention under pulsation. Compatible with air, inert gases, and water (non-potable).
Typical Applications:
- Pneumatic cylinder manifold connections
- CNC machine tool air supply lines
- Automated packaging line actuators
- Semiconductor fab equipment
- Plastic injection molding air circuits
Installation protocol:
Cut tubing square with dedicated cutter, deburr edges, and insert fully until audible click.
For maintenance, depress collar fully while pulling tubing. Max torque 45N·m during threading.
| Property | Property Value |
|---|---|
| sku | APC16-M20 |
| Insert Tube | 16mm |
| Threaded Port | M20 |
