Airtac APC Threaded Quick Connect Coupling APC4-01
$2.80
Regular price
$10.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC4-01
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation note:
Apply 1.5-2 turns of PTFE tape on male threads. For plastic tubing,
cut ends square and deburr before insertion. Maximum recommended
insertion force: 50N. Periodic check: Verify O-ring elasticity
every 5,000 operating cycles.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-01 Threaded Quick Connect Coupling Specifications
- Model: APC4-01 (Male Thread)
- Series: APC - Push-to-Connect Pneumatic Fittings
- Thread Standard: G1/8 (BSPP) / Optional M10×1.0 metric thread
- Tube OD Compatibility: 4mm (5/32")
- Material: Brass body with electroless nickel plating
- Seal: NBR (Nitrile) O-ring
- Max Working Pressure: 1.0 MPa (145 psi)
- Temperature Range: -5℃ to 80℃ (23°F to 176°F)
- Weight: 18g ±0.5g
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H)
- Thread Length: 8mm engagement
- Flow Rate: 120 NL/min (at 0.5 MPa)
- IP Rating: IP40 (dust protected)
- Vibration Resistance: ≤10 Hz @ 2mm amplitude
Single-touch pneumatic fitting with precision-machined threads and anti-vibration sleeve design. Features 360° rotatable collar for easy tube alignment and maintenance-free operation. The chrome-free surface treatment meets RoHS compliance for industrial hygiene requirements.
Typical Applications:
- Modular pneumatic circuit assembly lines
- CNC machine tool air supply connections
- Automated packaging equipment air lines
- Laboratory pneumatic instrument interfaces
- Robotic end-effector tooling air circuits
Installation note:
Apply 1.5-2 turns of PTFE tape on male threads. For plastic tubing,
cut ends square and deburr before insertion. Maximum recommended
insertion force: 50N. Periodic check: Verify O-ring elasticity
every 5,000 operating cycles.
| Property | Property Value |
|---|---|
| sku | APC4-01 |
| Insert Tube | <4mm> |
| Threaded Port | PT1/8 |
