Airtac APC Threaded Quick Connect Coupling APC4-02
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC4-02
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation note:
Ensure tubing is cut square and fully inserted until "click" sound.
For M5 threaded version, apply 0.8-1.2 N·m torque during installation.
Lubricate threads with PTFE tape for optimal sealing.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-02 Threaded Quick Connector Technical Details
- Model: APC4-02 (APC Series)
- Thread type: Male thread (external)
- Thread standard: PT1/8 (BSPP) / M5×0.8 optional
- Tube OD compatibility: 4mm (5/32") pneumatic tubing
- Material: Brass (nickel-plated) with PPS resin sleeve
- Seal material: NBR (Nitrile) rubber
- Max working pressure: 1.0 MPa (145 psi)
- Min burst pressure: 3.0 MPa (435 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Leakage rate: ≤0.1 Nml/min @ 0.5 MPa
- Weight: 24g ±1g
- Dimensions: 30mm (L) × 12mm (W) × 12mm (H)
- IP rating: IP40 (non-weatherproof design)
High-flow push-to-connect fitting with 360° rotatable sleeve for tool-free tube installation. Features double O-ring sealing and anti-vibration teeth for secure connections in dynamic pneumatic systems. Compatible with PU, NYLON, and PE tubing.
Typical Applications:
- Modular pneumatic circuit assembly lines
- Robotic end-effector tooling air supply
- CNC machine coolant control systems
- Semiconductor wafer handling equipment
- Industrial vacuum pick-and-place devices
Installation note:
Ensure tubing is cut square and fully inserted until "click" sound.
For M5 threaded version, apply 0.8-1.2 N·m torque during installation.
Lubricate threads with PTFE tape for optimal sealing.
| Property | Property Value |
|---|---|
| sku | APC4-02 |
| Insert Tube | <4mm> |
| Threaded Port | PT1/4 |
