Airtac APC Threaded Quick Connect Coupling APC4-M10
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-M10 Threaded Quick Connector Specifications
- Model: APC4-M10
- Series: APC (Advanced Pneumatic Connection)
- Thread type: M10×1.0 male thread (ISO 228/ISO 1179 standard)
- Tube OD compatibility: 4mm (flexible tubing)
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Peak temperature resistance: 120℃ (intermittent)
- Leakage rate: ≤0.1 Nml/min @ 0.5 MPa
- Installation torque: 10-12 N·m recommended
- Weight: 18.5g ±0.3g
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Thread engagement depth: 8mm minimum
- Vibration resistance: ≤50 m/s² (10-2000 Hz)
- Certifications: RoHS compliant, REACH tested
Precision-engineered push-to-connect fitting with 360° rotatable collar for tool-free tube installation. Features dual-stage sealing with dust-resistant cap retention. The tapered thread design prevents cross-threading during assembly. Compatible with air, inert gases, and mild hydraulic fluids (≤ISO VG32).
- Modular pneumatic circuit assembly lines
- CNC machine tool coolant distribution
- Robotic arm end-effector pneumatic controls
- Medical gas delivery systems (O₂/N₂)
- Semiconductor fab equipment air lines
- Electric vehicle battery cooling systems
Installation protocol:
Apply thread sealant only on male threads (PTFE tape recommended).
Hand-tighten until snug then apply 1/4 turn with wrench.
Replace O-ring every 5,000 connection cycles or 2 years.
| Property | Property Value |
|---|---|
| sku | APC4-M10 |
| Insert Tube | <4mm> |
| Threaded Port | M10 |
