Airtac APC Threaded Quick Connect Coupling APC4-M12
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-M12 Threaded Quick Connector Specifications
- Model: APC4-M12
- Type: Push-to-connect threaded fitting (straight type)
- Thread specification: M12×1.5 male thread
- Tube compatibility: 4mm OD (PU, nylon, or polyamide tubing)
- Body material: POM (polyoxymethylene) with brass insert
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Operating temperature: -20℃ to +80℃
- Pressure range: 0.3-1.5 MPa (43.5-217.5 PSI)
- Leakage rate: ≤0.1 NL/min @ 0.5 MPa
- Protection rating: IP40 (dust protected)
- Weight: 28g ±2g
- Dimensions: 40mm(L) × 16mm(W) × 16mm(H)
- Thread engagement depth: 8mm minimum
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
High-flow pneumatic connector with 45° tube release collar for tool-free maintenance. Features anti-vibration teeth and color-coded blue POM body for quick identification. The brass insert ensures precise M12 threading compatibility with ISO 1179-2 standards. Rated for 50,000+ connection cycles.
- Robotic end-effector pneumatic tooling
- CNC machine coolant line connections
- Factory automation sensor wiring protection
- Medical device compressed air distribution
- Electric vehicle battery cooling systems
Installation protocol:
Hand-tighten with <1.5Nm torque before final 180° wrench adjustment.
Always insert tubes perpendicularly until hearing audible "click".
For gas applications, apply thread sealant on male threads only.
| Property | Property Value |
|---|---|
| sku | APC4-M12 |
| Insert Tube | <4mm> |
| Threaded Port | M12 |
