Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation note:
Cut tubing square and deburr before insertion. Engage lock lever until audible click.
For gas applications, apply thread sealant only on male threads (not on tube connection side).
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-M6 Threaded Quick Connector Specifications
- Model: APC4-M6 (APC Series)
- Thread standard: M6×1.0 metric thread (male)
- Tube OD compatibility: 4mm (5/32") pneumatic tubing
- Material: Nickel-plated brass body, PPS resin lever
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa (435 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Peak temperature: 120℃ (intermittent)
- Flow rate: 250 NL/min (at 0.5 MPa)
- Leakage: <0.1 mL/min (under 0.5 MPa air pressure)
- Weight: 8.5g ±0.3g
- Dimensions: 23mm(L) × 16mm(W) × 16mm(H)
- IP rating: IP40 (dust protected)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-flow push-to-connect fitting with 360° rotatable collar for flexible hose routing. Features dual-stage sealing with dust-resistant lever lock mechanism. Compatible with air, water, and inert gases when using appropriate seals.
Typical Applications:
- Modular pneumatic assembly systems
- 3D printer filament dry box air supply
- Medical device pneumatic circuits
- Automated packaging machine tool changers
- Semiconductor wafer handling robots
Installation note:
Cut tubing square and deburr before insertion. Engage lock lever until audible click.
For gas applications, apply thread sealant only on male threads (not on tube connection side).
Special Features:
- Tool-free tube insertion/extraction
- Reusable up to 50 connection cycles
- Chemical-resistant to ISO 32-68 hydraulic fluids
- UV-stable version available (APC4-M6-UV)
| Property | Property Value |
|---|---|
| sku | APC4-M6 |
| Insert Tube | <4mm> |
| Threaded Port | M6 |
