Airtac APC Threaded Quick Connect Coupling APC4-M8
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC4-M8 Threaded Quick Connector Specifications
- Model: APC4-M8
- Type: Push-to-connect threaded fitting with metal release sleeve
- Thread specification: M8×1.0 male thread (ISO 1179 standard)
- Tube compatibility: Ø4mm OD pneumatic tubing
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile) rubber
- Operating pressure: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Leakage rate: ≤0.1 Nml/min @ 0.5 MPa
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- IP rating: IP40 (non-submerged environments)
- Weight: 15.2g ±0.5g
- Dimensions: 40mm(L) × 16mm(W) × 16mm(H)
Precision-engineered quick-disconnect fitting featuring a 360° rotatable threaded port for flexible installation. The zinc-nickel composite plating provides enhanced corrosion resistance exceeding 96hrs in salt spray tests. The dual-lock sleeve mechanism prevents accidental disconnection while allowing single-hand operation.
- Modular pneumatic assembly systems
- Robotic end-effector tool changers
- CNC machine coolant line connections
- Portable medical oxygen devices
- Semiconductor wafer handling equipment
- Electric vehicle battery cooling systems
Installation protocol:
Hand-tighten with 1/2 turn past finger-tight (max torque 1.2N·m).
For gas applications, apply PTFE tape on threads without blocking airflow path.
Replace O-rings every 5,000 cycles or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | APC4-M8 |
| Insert Tube | <4mm> |
| Threaded Port | M8 |
