Airtac APC Threaded Quick Connect Coupling APC6-M20
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC6-M20 Threaded Quick Connect Coupling Specifications
- Model: APC6-M20
- Thread type: M20×1.5 external thread (male)
- Tube OD compatibility: 6mm (1/4")
- Material: Nickel-plated brass body, PPS seal
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃
- Seal compatibility: Air, water, non-corrosive gases
- Thread torque resistance: 14-16 N·m
- Weight: 48g ±2g
- Dimensions: 45mm(L) × 20mm(W) × 32mm(H)
- Insertion force: ≤30N (with tube)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP54 (dust/water protected)
High-flow pneumatic connector with 90° push-to-connect design, featuring automatic sealing upon tube insertion. The dual-locking sleeve prevents accidental disconnection, while the anti-rotation hex base enables tool-free installation. Compatible with PU, nylon, and polyethylene tubing.
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Packaging machine air cylinder circuits
- Semiconductor cleanroom equipment
- Hydraulic test bench quick-disconnect systems
Installation note:
Apply 2-3 drops of silicone oil monthly on sleeve mechanism in high-cycle applications (>5,000 connects/day).
Ensure tube end is cut square and deburred before insertion.
| Property | Property Value |
|---|---|
| sku | APC6-M20 |
| Insert Tube | <6mm> |
| Threaded Port | M20 |
